EXHIBITION done by govind sharma

GODREJ

EXHIBITION

DESIGN OF AN EXHIBITION LAYOUT

OVERVIEW -

To design an exhibition for Godrej three divisions. The three divisions are Material Handling Division, EFACEC and Storage Solution Division. The project started with looking at the allotted space at exhibition site. Those products which are decided to be placed are made into small models. The models are scaled to 1:48. The project took 3 months to complete from design to implementation. It was a beautiful design journey.

Ideation phase:

Four Concepts


Scaled model ( 1:48 )

3D Design phase


CAD Modelling

Sketch up

Trial runs / experience on 1:1 scale

EXHIBITION done by govind sharma

Rendered

Final Design


Pre-production phase

READY

BANNERS

Preparing the various banners as per their respective position.

Production copy.jpg

Execution phase

Final_exhibiton copy.jpg

AND

FINALLY

THE MAIN DAY

THANK YOU
